Hydraulic Tilt Cylinder Ram Bucket Tip Suitable for Bobcat 753

Suitable for Bobcat Skid Steer Loader Models: S130, T140, 753, 763, 773 (s/n 509616001-509629999 & 509635001-later)

Specifications

Type: Hydraulic Tilt Cylinder Ram Bucket Tip

Warranty: 1 year

Bore: 3 1/2 ", 88.9 mm ID

Rod: 38.1 mm, 1.5" OD

Stroke: 14.5 ", 368.3 mm

Extended : 36.80 ", 934.72 mm

Retracted : 22.3 ", 584.2 mm

Reference Numbers: Suitable for 6804630, 6539931, 6586587, 6586586, 6805150, 7196894, 7135555

Note: If your machine has the earlier 3.25 " 82.55 mm ID Tilt Cylinder this is Not ! a substitute
